3S 40A BMS 11.1V 12.6V 18650 | 21700 Lithium Battery Protection Board with 100mA Balancing Feature in Pakistan

The 3 Series 40A 18650 Lithium Battery Protection Board 11.1V 12.6V with Balance for Drill Motor Lipo Cell Module comes with recovery function-AUTO Recovery and Integrated 10 low load resistance MOS tube. It provides a continuous discharge of 40A, 100mA balanced current, for electric drill/sprayer/LED lights/low power inverter.  (if the cooling environment is not good, please reduce the load current use).The Scope of Nominal voltage of 3.6V, 3.7V lithium battery (including 18650,26650, a polymer lithium battery) where Charging voltage can be range between 16.8V to 18.1V The board operates smoothly with Continuous charge current of (upper limit): 20A. The balanced version is suitable for starting current below 80A, power 135W below the drill (with balance).

Specification:

• String: 3 Strigns
• Overcharge detection voltage (V): 4.25 ± 0.025
• Over-discharge detection voltage (V): 2.50 ± 0.08
• Over current Protection (A): 40
• Working current (A): 20
• Operating Temperature (°C): – 40 ~ +85
• Length (mm): 60
• Width (mm): 41
• Height (mm): 3.5
